Description
ThinkSystem SR630 V2 6xSAS/SATA 4xAnybay 2.5 BP SAS/SATA Cable Kit
1 Power cable, 330 mm (x1)
- From the front backplane to the system board
2 Power cable, 230 mm (x1)
- From the system board to the CFF RAID adapter
3 SAS/SATA cable, 960 mm (x1)
- From the front backplane to the system board
4 SAS/SATA cable, 780 mm (x1)
- From the front backplane to the system board
5 SAS/SATA cable, 175 mm (x1)
- From the front backplane to the CFF RAID adapter
6 SAS/SATA cable, 110 mm (x1)
- From the front backplane to the CFF RAID adapter
7 SAS/SATA cable, 210 mm (x1)
- From the front backplane to the CFF RAID adapter
8 PCIe cable, 470 mm (x1)
- From the system board to the CFF RAID adapter
9 PCIe cable, 425 mm (x1)
- From the system board to the CFF RAID adapter
10 SAS/SATA cable, 690/860 mm (x1)
- From the front backplane to the SFF RAID adapter
11 SAS/SATA cable, 580 mm (x1)
- From the front backplane to the SFF RAID adapter
12 SAS/SATA cable, 690/860 mm (x1)
- From the front backplane to the SFF RAID adapter
13 SAS/SATA cable, 690 mm (x1)
- From the front backplane to the SFF RAID adapter
