TP-Link

TP-Link ER701-5G Outdoor Omada 5G Gateway with Dual Nano SIM Support, PoE Power Input, 2.5G Ethernet Port, Enterprise Routing, VLAN, Firewall

SKU:
ER701-5G-OUTDOOR
Plus Shipping
Calculated at Checkout

Product images are used for illustration purposes only.

View Alternatives


×

This stock info gives you an outline of whether a product on our webstore is available to purchase or not.

Stock Availability:

In Stock: Stock is available and ready to ship.

Available to Click & Collect from MediaForm warehouse: Stock is available for customer to pick-up from either our Sydney, Brisbane or Melbourne warehouse.

SYDNEY PICK-UP HOURS:  Monday to Friday, 10am to 2pm
BRISBANE PICK-UP HOURS:  Monday to Friday, 9am to 4pm
MELBOURNE PICK-UP HOURS:  Temporarily Unavailable

Available to Ship from Supplier Warehouse: Stock is available to ship to customer from our Supplier warehouse but not available to pick-up.

Call us for ETA: Stock is unavailable in MediaForm or supplier warehouses. Product may be on back order (contact us for ETA date) or has been discontinued.

Please understand we do our best to have stock availablity up to date on our webstore but there could be discrepancy at times due to our inventory data not being real-time.

$1,442.23 Inc. GST
$1,311.12 Ex. GST



Customer Click & Collect:   View our conditions here.
For Returns & Refunds:   View our policy here.
Customers Also Purchased  CUSTOMERS ALSO PURCHASED

Description

TP-Link ER701-5G Outdoor Omada 5G Gateway with Dual Nano SIM Support, PoE Power Input, 2.5G Ethernet Port, Enterprise Routing, VLAN, Firewall, and Omada Cloud Management


Device


•Outdoor 5G Gateway / Router

Dual
•Nano SI
•PoE powered
•

Omada-managed


Cellular – 5G NR

•
Bands:

n1 / n3 / n5 / n7 / n8 / n20 / n26 / n28 / n38 / n40 / n41 / n75 / n76 / n77 / n78
•

Frequencies:

700 / 800 / 850 / 900 / 1500 / 1800 / 2100 / 2300 / 2500 / 2600 / 3500 / 3700 MHz

•
SA:

7.01 Gbps ↓ / 1.25 Gbps ↑


•NSA:
4.5 Gbps ↓ / 730 Mbps ↑


Cellular – 4G LTE

•
FDD:

B1 / B3 / B5 / B7 / B8 / B20 / B26 / B28 / B32


•TDD:
B38 / B40 / B41 / B42 / B43
•

Speed:
1.6 Gbps ↓ / 211 Mbps ↑


Cellular – 3G
•

WCDMA:

B1 / B5 / B8


SIM


•1 × Dual Nano SIM slot
•

Failover supported


Ethernet


•1 × 2.5G RJ45


•10 / 100 / 1000 / 2500 Mbps


•PoE:


•802.3at (42–57 V, 0.6 A)
•

Passive 48 V


Wireless (Local)

•
2.4 GHz only

•
802.11 b / g / n

•
150 Mbps max
•

WPA / WPA2-Personal

•
1 SSID


•TX power control
•

Auto channel selection
Routing / Switching


•Static routing
•

OSPF (Standalone)
•

Bridge VLAN

•
802.1Q VLAN
•

Multi-Net interfaces


NAT / Firewall
•

Multi-Net NAT
•

Virtual server
•

Port triggering
•

NAT-DMZ


•ALG: FTP / SIP / IPSec / PPTP / H.323
•

UPnP


•Stateful ACL
Storage / Memory


•4 GB eMMC


•2 GB LPDDR4x
Power

Max consumption:
•15.3 W
Physical

Dimensions:
•183 × 110 × 36 mm

•
Wall / pole / window mount
•

Waterproof kit included

Warranty Period: 3-Year
