TP-Link

TP-Link Omada ES206X-M2 2.5G Easy Managed Network Switch, 5× 2.5GbE Ports + 10G SFP+, Fanless Design, VLAN, QoS, IGMP Snooping, 5-Year Warranty

SKU:
ES206X-M2
Plus Shipping
Calculated at Checkout

Product images are used for illustration purposes only.

View Alternatives


×

This stock info gives you an outline of whether a product on our webstore is available to purchase or not.

Stock Availability:

In Stock: Stock is available and ready to ship.

Available to Click & Collect from MediaForm warehouse: Stock is available for customer to pick-up from either our Sydney, Brisbane or Melbourne warehouse.

SYDNEY PICK-UP HOURS:  Monday to Friday, 10am to 2pm
BRISBANE PICK-UP HOURS:  Monday to Friday, 9am to 4pm
MELBOURNE PICK-UP HOURS:  Temporarily Unavailable

Available to Ship from Supplier Warehouse: Stock is available to ship to customer from our Supplier warehouse but not available to pick-up.

Call us for ETA: Stock is unavailable in MediaForm or supplier warehouses. Product may be on back order (contact us for ETA date) or has been discontinued.

Please understand we do our best to have stock availablity up to date on our webstore but there could be discrepancy at times due to our inventory data not being real-time.

$111.67 Inc. GST
$101.52 Ex. GST



Customer Click & Collect:   View our conditions here.
For Returns & Refunds:   View our policy here.
Customers Also Purchased  CUSTOMERS ALSO PURCHASED

Description

TP-Link Omada ES206X-M2 2.5G Easy Managed Network Switch, 5× 2.5GbE Ports + 10G SFP+, Fanless Design, VLAN, QoS, IGMP Snooping, 5-Year Warranty

SPECIFICATION

HARDWARE FEATURES

Interface
•5× 2.5 Gbps RJ45 Ports
•1× 10 Gbps SFP+ Slot
•Auto-Negotiation/Auto MDI/MDIX
Fan Quantity
•Fanless
Installation
•Desktop
•Wall Mount
Physical Security Lock
•√
Power Supply
•DC Power Adapter
•(Output: 12 VDC / 1 A)
Dimensions ( W x D x H )
•6.2 × 4.0 × 1.0 in (158 × 100.7 × 25.4 mm)
Surge Protection
•±6kV for Ethernet Ports

SOFTWARE FEATURES

Quality of Service
• Port-based/802.1p/DSCP QoS△
• 8 Priority Queues
• Priority Schedule Mode
- WRR (Weighted Round Robin)
• Queue Weight Config
• Bandwidth Control
- Port-Based Rating Limit
• Storm Control
- Multiple Control Modes (kbps/pps)
- Broadcast/Multicast/Unknown-Unicast Control

L2 Features
• Static Link Aggregation
• Loop Prevention / Loopback Detection
• Flow Control
- 802.3x Flow Control
• Mirroring
- Port Mirroring
- One-to-One
- Many-to-One
- Ingress/Egress/Both
• Port Statistics
- Port Mirror Status
- Traffic Statistics
• 802.1ab LLDP

L2 Multicast
• IGMP Snooping
- IGMP v1/v2/v3 Snooping
- Fast Leave

VLAN
• MTU VLAN
• Port-Based VLAN
• 802.1Q Tag VLAN
- Max 32 VLAN Groups
- 4K VID
Transmission Method
•Store-And-Forward

Warranty Period: 5-Year
